Honeywell Voyager 1400g, 1D, PDF, multi-IF, wit 1400GP…

Bewaar
  • Aantal keer bekeken 174x bekeken
  • Datum geplaatst 7 jaar geleden geplaatst

Kenmerken


Levering
Niet van toepassing
Staat van het product
Nieuw
Type advertentie
Aangeboden
Type prijs
Op aanvraag

Omschrijving


handscanner, retail, 1D, PDF 417, IR barcode sensor , CodeGate function, 0-28cm leesafstand, multi interface (RS232, KBW, USB), protection class: IP42, apart bestellen, interface kabel, kleur: wit
Honeywell Voyager 1400g Affordable area imager for first-time users
1D area imager for handheld and presentation modes
Simple upgrades for PDF and 2D barcodes
Productive: high speed omni-directional scans
Withstands drops from 1.5 m; protection class IP42
Automatic motion recognition, optional with base
An area imager which comes either as a 1D or 2D variant, plus is flexible according to your requirements - that sums up the Honeywell Voyager 1400g. With it you achieve scanning speeds formerly only known from laser scanners - ideal for significantly increasing user productivity. It scans barcodes omni-directionally, thus saving the time normally spent on lining up individual codes. Whether reading from labels or displays, the imager reads barcodes quickly and reliably.
Maximize the performance of the Voyager 1400g whenever necessary: with a simple software upgrade the 1D area imager becomes a powerful scanner for PDF and/or all common 2D barcodes. This keeps you on the safe side in case suppliers or legal regulations require 2D compatibility. This also speaks for the scanner during the decision-making process of cost-conscious users, since they only pay for what they actually need - while keeping the option for future upgrades open. An increase in performance is possible at any time - when purchasing or at a later time, when the scanning requirements increase, or when the area of operation changes.
The optionally available base transforms the Voyager 1400g into a professional presentation scanner in seconds, allowing for usage in applications requiring that both hands remain free. A particular advantage: the scanner recognizes the mode automatically, so that even quick changes can be implemented.
Thanks to its ergonomic form the Voyager sits comfortably in your hand. With a weight of a mere 119 grams, it allows for tireless operation. Its housing is robust and easily withstands even repeated drops onto hard concrete floors out of an average height of 1.5 meters. It is IP42 certified, meaning that the Voyager 1400g also resists dust and splash water. With the standard multi-interface you receive the complete connection variety: USB, KBW, RS232 and RS485 interfaces are integrated direct from the factory. Its power consumption during operation is a low 2 Watts, plus a 5-year warranty secure your investment for many years.
Voyager® 1400g Linear/Area-Imaging Scanner
Honeywell's Voyager 1400g is the ultimate 2D barcode scanner. This linear imager is capable of reading even poor quality and mobile 2D barcodes. 2D barcode scanners are becoming increasingly popular across a wide range of industries for a number of reasons. Enterprises have a growing need to capture large amounts of data, despite space constraints, while others are being required to read 2D barcodes due to government regulations or supplier mandates. An even larger group of enterprises simply have the desire to leverage emerging trends that require linear imagers with advanced area-imaging technology, without needing to purchase additional scanning hardware. The 1400g's features go above and beyond in meeting 2D scanning needs.
Voyager 1400g Area-Imaging Scanner
2D bar codes are becoming increasingly popular across a wide range of
industries for a number of reasons. Some enterprises have a desire to
capture large amounts of data, despite space constraints, while others
are being required to read 2D bar codes due to government regulations
or supplier mandates. And an even larger group of enterprises simply
have the desire to leverage emerging trends that require area-imaging
technology, today or in the future, without needing to purchase additional
scanning hardware.
Enterprises that recognize the importance of upgrading to area-imaging
scanners are generally unwilling to accept a decline in scan performance.
They are also looking for a solution that is capable of reading traditional
paper-based bar codes, as well as bar codes found on alternative
mediums, such as mobile phone screens.
Built on the platform of Honeywell’s world-renowned Voyager series of
hand-held linear scanners, the Voyager 1400g delivers omnidirectional
reading of linear bar codes, plus the ability to affordably upgrade
the device to enable PDF and 2D bar code scanning—at the time of
purchase or as scanning needs evolve. Performing at speeds that are
comparable to laser-based scanners, the versatile and reliable Voyager
1400g can be customized to meet current and future scanning needs,
lowering the total cost of ownership.
With no need for additional functionality beyond linear and 2D bar code
scanning, many enterprises are unwilling to pay for fully-featured areaimaging
scanners. The Voyager 1400g enables PDF and 2D bar code
scanning without extra value-added features, such as advanced image
capture and processing applications, allowing Honeywell to offer 2D
scanning at an attractive price.
The Voyager 1400g offers an exceptional value for enterprises that
require the versatility of area-imaging technology today or may need
it in the future. Produced by a company with more than 15 years of
experience in engineering quality area-imaging solutions, Honeywell’s
Voyager 1400g area-imaging scanner is a smart investment.
Features
• Reliable Data Collection: Offers omnidirectional reading of virtually all linear bar codes and the most widely used 2D bar codes, including poor quality and mobile bar codes
• Remote MasterMind™ Ready: Reduces total cost of ownership by providing a turnkey remote device management solution that easily manages and tracks
usage of installed devices
• Future Proof: Delivers affordable scanning of 2D bar codes, allowing enterprises to meet their current and future bar code scanning needs with a single device
• Flexible Licensing Solution: Meets diverse scanning requirements by offering models with basic functionality
—purchase software licenses to enable additional functionality as the need arises
Voyager 1400g Technical Specifications
Mechanical
Dimensions (LxWxH) 43 mm x 180 mm x 66 mm (1.7˝ x 7.1˝ x 2.6˝)
Weight 119 g (4.2 oz)
Electrical
Input Voltage 4.0 to 5.5 VDC
Operating Power 2 W (400mA at 5 VDC)
Standby Power 0.45 W (90mA at 5 VDC)
Host System Interfaces USB, Keyboard Wedge, RS232, IBM 46xx (RS485)
Environmental
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -40°C to 60°C (-40°F to 140°F)
Humidity 0% to 95% relative humidity, non-condensing
Drop Designed to withstand 30 1.5 m (5´) drops to concrete
Environmental Sealing IP42
Light Levels 0 to 100,000 lux (9,290 foot-candles)
Scan Performance
Scan Pattern Area Image (640 x 480 pixel array)
Motion Tolerance Up to 10 cm/s (4 in/s) for 13 mil UPC at optimal focus
Scan Angle Horizontal 42.4°; Vertical: 30.8°
Symbol Contrast 35% minimum reflectance difference
Pitch, Skew 60°, 70°
Decode Capability:
1400g1D: all standard 1D symbologies
1400gPDF: all standard 1D and PDF417 symbologies
1400g2D: all standard 1D, PDF417 and 2D symbologies
Warranty 5 year factory warranty
For a complete listing of all compliance approvals and certifications, please visit www.honeywellaidc.com/compliance
For a complete listing of all supported bar code symbologies, please visit www.honeywellaidc.com/symbologies
Preliminary Specifications
Subject to Change
Typical Performance
Narrow Width Depth of Field
5 mil Code 39 28 mm - 90 mm (1.1˝ - 3.5˝)
13 mil UPC 25 mm - 250 mm (1.0˝ - 9.8˝)
20 mil Code 39 30 mm - 350 mm (1.2˝ - 13.7˝)
6.7 mil PDF417 25 mm - 90 mm (1.0˝ - 3.5˝)
10 mil DM** 25 mm - 95 mm (1.0˝ - 3.7˝)
20 mil QR 15 mm - 195 mm (0.6˝ - 7.7˝)
*Performance may be impacted by bar code quality andn environmental conditions
**Data Matrix (DM)
For more information:
www.honeywellaidc.com
Honeywell Scanning & Mobility
9680 Old Bailes Road
Fort Mill, SC 29707
800.582.4263
www.honeywell.com
Alle modellen: / All models:
-Honeywell Voyager 1400g, 1D, PDF, multi-IF, wit (hw1400w - 1400GPDF-1)
handscanner, retail, 1D, PDF 417, IR barcode sensor , CodeGate function, 0-28cm leesafstand, multi interface (RS232, KBW, USB), protection class: IP42, apart bestellen, interface kabel, kleur: wit
Garantie: Warranty:
60 Maanden, 60 Months
Uitbreiding garantie met, Extended warranty with::
-PE Service +8%
-FullCover +18%
Beschikbaar toebehoren: Available accessories:
-Honeywell power supply, EU (ms9520nt - 46-00526)
power supply, EU, 1.0A at 5.2VDC, 90-255VAC at 50-60Hz46
-Honeywell cable, KBW (hw1200cabkbw - CBL-720-300-C00)
cable, KBW, coiled, black, 3 m, 5V external power with option for host power
-Honeywell holder (hw1200hold - HOLDER-004-U)
desktop/wall mount holder for Honeywell 1200g/1400g
-Honeywell stand (hw1200stand - STND-19R02-002-4)
Stand, 19cm stand height, dark grey
-Honeywell USB-cable (hw1200ucab - CBL-500-300-C00)
USB-cable, coiled, black, 3m
-Honeywell cable, USB (hw1200ucab2 - CBL-500-300-S00)
cable, USB, straight, black, 3m
-Honeywell USB-cable (hw1200ucab3 - CBL-500-500-C00)
USB-cable, coiled, black, 16.4'
-Honeywell Software (hw1400sw2d - SW-2D-scanner)
2D license key for Honeywell Voyager 1400g series
-Honeywell Kabel, RS232 (hwcab020 - CBL-020-300-C00)
RS232 Cable, 5V, DB9 Female, coiled, black, 3m
Naast ons uitgebreide aanbod, kunnen wij ook de volgende versies en accessoires van dit product leveren. Contacteer ons.
In addition to our extensive offer, we also provide the following versions and accessories of this product. Contact us.
Type Art.nr.fabr.
-USB Kit: Omni-directional 1D, PDF417, 2D, black, USB Type A 1.5m straight cable (CBL-500-150-S00) 1400g2D-2USB
-USB Kit: Omni-directional, 1D, black, USB Type A 1.5m straight cable (CBL-500-150-S00) 1400g1D-2USB
-USB Kit: Omni-directional 1D, PDF417, black, USB Type A 1.5m straight cable (CBL-500-150-S00) 1400gPDF-2USB
-Scanner Only: Omni-directional, 1D, black, RS232/USB/KBW/IBM 1400g1D-2
-Voyager 1400G, 1 DAY, COMPREHENSIVE, 3YR HSVC1400g-SMS3
-Voyager 1400G, 1 DAY, COMPREHENSIVE, 5YR HSVC1400g-SMS5
-Voyager 1400G, 1 DAY, COMPREHENSIVE, 1YR E-HSVC1400g-SMS1
-Software: 2D license key for Voyager 1400g series of products SW-2D-scanner
-Software: PDF417 license key for Voyager 1400g series of products SW-PDF-scanner
Prijs op aanvraag! Price on request!
