Honeywell Voyager 1202g Laser scanner Wireless Hand He…

Bewaar
  • Aantal keer bekeken 158x bekeken
  • Datum geplaatst 7 jaar geleden geplaatst

Kenmerken


Levering
Niet van toepassing
Staat van het product
Nieuw
Type advertentie
Aangeboden
Type prijs
Op aanvraag

Omschrijving

Handy Bluetooth scanner boasting practical features
Honeywell Voyager 1202g
Cordless laser scanner for flexible use in retail, stocktaking and manufacturing
Bluetooth class 2 with a range of up to 10 m
Long battery life and tools-free exchange
Multi-interface: USB, KBW and RS232 in one device
Memory storage when out of range to receiver cradle
The Voyager 1202g is the direct successor to the Voyager BT 9535. Its extremely improved performance is based on the 1200g, also adding a Bluetooth device to the series. The handy scanner ideally suits checkout areas and smaller warehousing and manufacturing facilities.
The Voyager 1202g is very user-friendly: The base station is easy to connect to a host through its plug & play multi-interface. To save space you simply mount it vertically. Thanks to Bluetooth class 2, users scan 1D and GS1 barcodes within a 10 m radius (up to 30 m with a clear line of sight) without cable tangle. It is easy to find the scanner after it was misplaced in a rush; with the press of a button on the cradle, the scanner will start to blink and beep. The 1800 mAh battery provides 12 hours of operation (or 45,000 scans) and recharges rapidly. It can also be replaced in the blink of an eye and without any tools. Weighing only 180 grams, it does not tire out the user.
Voyager® 1202g Wireless Single-Line Laser Scanner
Honeywell’s Voyager™ 1202g hand-held laser barcode scanner incorporates the freedom of Bluetooth® wireless technology and offers a field-replaceable battery that can be quickly and easily exchanged. The 1202g single-line wireless scanner delivers the aggressive linear barcode scanning that users have come to expect from the world-renowned Voyager family of scanners. Read even the poorest quality barcodes with advanced laser scanning technology that only Honeywell can deliver.
Voyager 1202g Wireless Single-Line Laser Scanner
Honeywell’s Voyager™ 1202g single-line laser scanner incorporates the
freedom of Bluetooth® wireless technology and offers a field-replaceable
battery that can be quickly and easily exchanged. The new 1202g delivers the aggressive linear bar code scanning that users have come to expect from the world-renowned Voyager family of scanners.
Voyager 1202g incorporates a Bluetooth® Class 2, v2.1 radio, enabling
unrestricted movement up to 10 meters (33 feet) from the base.
Honeywell has also demonstrated Bluetooth® Class 2 communication ranges of up to 30 meters (100 feet) with a clear line of sight from the base. The 1202g offers users added safety and a wider range of movement by eliminating tethered cables. For added convenience, the included paging system helps locate misplaced scanners with visual and auditory signals.
The field-removable battery can be exchanged quickly and easily, without the use of tools. The user-preferred, long-lasting Lithium ion battery provides 12 hours or more of scanning time and 45,000 scans per charge. The 1202g recharges quickly, resulting in increased throughput.
Built on the platform of the corded Voyager 1200g, the 1202g is optimized for scanning linear bar codes, including poorly printed and damaged codes. Voyager 1202g allows enterprises to minimize manual data entry, leading to increased productivity and reduction in errors.
This plug and play scanner incorporates a multi-interface design with automatic interface detection. Voyager 1202g automatically configures itself to the appropriate interface, shortening the installation process.
1202g’s easy installation will benefit users in environments such as retail stores, hospitals, and light manufacturing facilities. The base can be desk or wall mounted to accommodate a variety of workstation layouts.
Features
• Bluetooth® Wireless Technology: Facilitates scanning of all standard 1D bar codes 10 meters (33 feet) or more away from the base, depending on the user’s environment
• Long Battery Life and Tool-Free Battery Removal: The user-preferred Lithium ion battery provides 12 hours or more of use, depending on scanning volume, and the field-replaceable battery can be exchanged quickly and easily, without the use of tools
• Automatic Interface Configuration: Supports all popular interfaces in one device, replacing the time consuming process of scanning programming bar codes with automatic interface detection and configuration
• Excellent Poor Quality Code Reading: Increases throughput and reduces the potential for hand-keyed errors by quickly scanning a variety of 1D bar codes,
including those that are damaged or smudged
• Paging Functionality: Simply press the button on the base to locate your lost scanner; Voyager 1202g responds with a series of beeps and blinking lights on its indicator panel
• Remote MasterMind™ Ready: Reduces total cost of ownership by providing a turnkey remote device management solution that easily manages and tracks usage of installed devices
Voyager 1202g Technical Specifications
Wireless
Radio/Range:
2.4 to 2.5 GHz (ISM Band) Adaptive Frequency Hopping Bluetooth v2.1; Class 2: 10m (33’) line of sight
Data Rate (Transmission Rate) Up to 3 Mbps
Battery 1800 mAh Lithium ion minimum
Number of Scans Up to 45,000 scans per charge
Expected Hours of Operation 12 hours
Expected Charge Time 4 hours
Mechanical/Electrical
Dimensions (LxWxH) Scanner: Voyager 1202g:
180 mm x 66 mm x 92 mm (7.1˝ x 2.6˝ x 3.6˝)
Weight Scanner: Voyager 1202g: 180 g (6.3 oz) (includes battery)
Operating Power (Charging) Scanner: Voyager 1202g N/A
Non-Charging Power Scanner: Voyager 1202g N/A
Host System Interfaces Scanner: Voyager 1202g N/A
Charge and Communication Base: CCB00-010BT
Dimensions (LxWxH) 200 mm x 67 mm x 97 mm (7.9˝ x 2.6˝ x 3.8˝)
Weight 185 g (6.5 oz)
Operating Power (Charging):
5 W (1 A at 5 V with power supply); 2.5W (0.5 A at 5 V with USB)
Non-Charging Power 0.625 W (0.125 A at 5 V)
Host System Interfaces USB, Keyboard Wedge, RS232, IBM 46xx (RS485)
Environmental
Operating Temperature Scanner: Voyager 1202g 5°C to 40°C (41°F to 104°F)
Storage Temperature with Battery Scanner: Voyager 1202g:
-5°C to 35°C (23°F to 95°F)
Humidity Scanner: Voyager 1202g 0 to 95% relative humidity, non-condensing
Drop Scanner: Voyager 1202g:
Designed to withstand 30 1.5 m (5´) drops to concrete
Environmental Sealing Scanner: Voyager 1202g IP42
Light Levels Scanner: Voyager 1202g 0 to 70,000 lux (6,500 foot-candles)
Charge and Communication Base: CCB00-010BT
Operating Temperature:
Charging: 5°C to 40°C (41°F to 104°F);
Non-Charging: 0°C to 50°C (32°F to 122°F)
Storage Temperature with Battery -5°C to 35°C (23°F to 95°F)
Humidity 0 to 95% relative humidity, non-condensing
Drop Designed to withstand 30 1 m (3.3´) drops to concrete
Environmental Sealing IP42
Light Levels N/A
Scan Performance
Scan Pattern Single scan line
Scan Speed (laser only) 100 scan lines per second
Scan Angle Horizontal: 30°
Print Contrast 10% minimum reflectance difference
Pitch, Skew 60°, 60°
Decode Capabilities:
Reads standard 1D and GS1 DataBar symbologies. (Note: Decode capabilities dependent on kit configuration)
Warranty 3 year factory warranty (Note: battery warranty is 1 year)
(SR) Typical Performance*
Narrow Width Depth of Field
5 mil 27 mm - 151 mm (1.1˝ - 5.9˝)
7.5 mil 16 mm - 216 mm (0.6˝ - 8.5˝)
10 mil 0 mm - 277 mm (0˝ - 10.9˝)
13 mil 0 mm - 311 mm (0˝ - 12.2˝)
20 mil 0 mm - 367 mm (0˝ - 14.4˝)
*Resolution: 3.5 mil
*Performance may be impacted by bar code quality and environmental conditions
For a complete listing of all compliance approvals and certifications, please visit www.honeywellaidc.com/compliance
For a complete listing of all supported bar code symbologies, please visit www.honeywellaidc.com/symbologies
For more information:
www.honeywellaidc.com
Honeywell Scanning & Mobility
9680 Old Bailes Road
Fort Mill, SC 29707
800.582.4263
www.honeywell.com
Alle modellen: / All models:
-Honeywell Voyager 1202g, BT, 1D, licht grijs (hw1202 - 1202g-1)
Bluetooth scanner , 1D, laser, IR barcode sensor , CodeGate function, 100 scans/s, reikwijdte, 10 m, IP42, incl.: accu, apart bestellen, interface kabel, cradle, voeding, kleur: licht grijs
-Honeywell Voyager 1202g, BT, 1D, multi-IF, kabel (KBW), licht grijs (hw1202kkit - 1202G-K-Kit)
Bluetooth scanner , 1D, laser, IR barcode sensor , CodeGate function, 100 scans/s, reikwijdte, 10 m, multi interface (RS232, KBW, USB), IP42, incl.: kabel (KBW), cradle, accu, apart bestellen, voeding, kleur: licht grijs
-Honeywell Voyager 1202g, BT, 1D, multi-IF, kabel (KBW), zwart (hw1202kswkit - 1202G-KSW-Kit)
Bluetooth scanner , 1D, laser, IR barcode sensor , CodeGate function, 100 scans/s, reikwijdte, 10 m, multi interface (RS232, KBW, USB), IP42, incl.: kabel (KBW), cradle, accu, apart bestellen, voeding, kleur: zwart
-Honeywell Voyager 1202g, BT, 1D, zwart (hw1202sw - 1202g-2)
Bluetooth scanner , 1D, laser, IR barcode sensor , CodeGate function, 100 scans/s, reikwijdte, 10 m, IP42, incl.: accu, apart bestellen, interface kabel, cradle, voeding, kleur: zwart
-Honeywell Voyager 1202g, BT, 1D, multi-IF, kabel (USB), licht grijs (hw1202ukit - 1202g-1USB-5)
Bluetooth scanner , 1D, laser, IR barcode sensor , CodeGate function, 100 scans/s, reikwijdte, 10 m, multi interface (RS232, KBW, USB), IP42, incl.: kabel (USB), cradle, accu, kleur: licht grijs
-Honeywell Voyager 1202g, BT, 1D, multi-IF, kabel (USB), zwart
(hw1202uswkit - 1202g-2USB-5)
Voordelig geprijsde demo/gebruikt apparaat beschikbaar van dit artikel
Bluetooth scanner , 1D, laser, IR barcode sensor , CodeGate function, 100 scans/s, reikwijdte, 10 m, multi interface (RS232, KBW, USB), IP42, incl.: kabel (USB), cradle, accu, kleur: zwart
Garantie: Warranty:
36 Maanden, 36 Months
Uitbreiding garantie met, Extended warranty with::
-PE Service +8%
-FullCover + 18%
Beschikbaar toebehoren: Available accessories:
-Honeywell cable, KBW (hw1200cabkbw - CBL-720-300-C00)
cable, KBW, coiled, black, 3 m, 5V external power with option for host power
-Honeywell USB-cable (hw1200ucab - CBL-500-300-C00)
USB-cable, coiled, black, 3m
-Honeywell cable, USB (hw1200ucab2 - CBL-500-300-S00)
cable, USB, straight, black, 3m
-Honeywell USB-cable (hw1200ucab3 - CBL-500-500-C00)
USB-cable, coiled, black, 16.4'
-Honeywell Cradle (hw1202base - CCB00-010BT-01N)
10m BT Charge/Comm base (only; cable and power must be purchased separately)
-Honeywell Standard Battery (hwbat - 100000495)
Standard Lithium-ion battery for Honeywell Voyager 1202, Xenon 1902, 3820, 3820i, 4820, and 4820i cordless scanners
-Honeywell Kabel, RS232 (hwcab020 - CBL-020-300-C00)
RS232 Cable, 5V, DB9 Female, coiled, black, 3m
-Honeywell RS232 cable, coiled, black (hwcab220 - CBL-220-300-C00)
Cable: RS232 (+5V signals), black, DB9 Male, 3m (9.8''), coiled,external power with option for host power on pin 9 for connection to Wincor Beetle
-Honeywell Cable, RS232, coiled, black (hwcab320 - CBL-320-300-C00)
RS232-Kabel (+/-12V signals), 3m (coiled), external power with option for host power on pin 9, black
-Honeywell IBM cable 46xx, black, straight (hwcabibm2 - CBL-600-300-S00)
Cable: IBM 46xx Port 9b, black, 3m (9.8´), straight, 12V host power
-Honeywell Power Supply (hwpsu5v4 - PS-05-1000W-C)
Power supply, 5V, 90-255VAC, EU Plug
-Honeywell USB cable, black, 3m, coiled (hwucab12 - CBL-503-300-C00)
Cable: USB, black, 12V locking, 3m (9.8´), coiled, 5V host power
-Cable: RS232 (5V signals) (ms24xxcabr3 - CBL-420-300-C00)
Cable: RS232 (5V signals), Honeywell Bioptic Stratos Aux, black, 10 pin
Naast ons uitgebreide aanbod, kunnen wij ook de volgende versies en accessoires van dit product leveren. Contacteer ons.
In addition to our extensive offer, we also provide the following versions and accessories of this product. Contact us.
Type Art.nr.fabr.
-Cable: RS232 (+/-12V signals), Verifone Ruby, Sapphire and Topaz Terminals, black, 8 pin modular, straight, host power on pin 8 CBL-431-300-S00
-Cable: RS232 (5V signals), Gilbarco terminal, black, 8 pin modular, 3m (9.8´), straight CBL-GIL-300-S00-01
-Cable: RS232 (5V signals), Gilbarco terminal, black, DB9 Female, 3m (9.8´), straight CBL-GIL-300-S00-02
-Cable: RS232 (5V signals), NCR 787x, black, 8 pin modular, 3m (9.8´), straight, external power with option for 5V host power on pin 1 CBL-NCR-300-S00
-Cable: RS232 (+/-12V signals), Radiant 1550 POS terminal, black, 6-pin modular, 3m (9.8´), straight, host power on pin 6 CBL-430-300-S00
Prijs op aanvraag! Price on request!
