Honeywell Voyager 1200g Barcode scanners

Bewaar
  • Aantal keer bekeken 181x bekeken
  • Datum geplaatst 7 jaar geleden geplaatst

Kenmerken


Levering
Niet van toepassing
Staat van het product
Nieuw
Type advertentie
Aangeboden
Type prijs
Op aanvraag

Omschrijving

Revolutionary laser scanner for universal use
Honeywell Voyager 1200g
Worldwide successful laser scanner
Use as hand or presentation scanner (stand optional)
Futuristic design and high-end performance
Aggressive reading for damaged or small barcodes
Multi-interface: USB, KBW and RS232 in one device
Honeywell expands its family of best-selling handheld laser scanners with their Voyager 1200g, which is an especially high-performance barcode reader. The scanner boasts high-tech components contained within the familiar futuristic housing, which has also been optimised: the single-line laser scans barcodes most accurately and even poorly printed, damaged or smudged codes are read easily. Being highly versatile, the device suits any application. Whether at the checkout, in the warehouse, the workshop or the laboratory – it always makes a good impression.
The Voyager 1200g is a truly universal solution: it not only scans all 1D and GS1 DataBar codes, it aggressive engine also reads the smallest codes up to 3.5 mil. Thus exceptionally flexible, the Voyager 1200g makes other scanners redundant. Furthermore, it includes a multi-interface for USB, KBW and RS232 connection that is automatically identified – a single device which is thus compatible with almost any system.
Using the optional scan stand, you turn the handheld scanner into a desktop scanner for the table or counter in no time. The scanner detects when it is placed in the stand and switches to »Presentation Mode« automatically. Thanks to its object recognition sensor, users simply pass the goods in front the scanner and achieve high throughput.
The Honeywell Voyager 1200g naturally features the popular CodeGate technology, which makes working with lists an easy task. While CodeGate is active, the scanner reads all codes automatically but does not transfer them; before transmitting the data, the user must confirm the code by pressing the CodeGate button. Whenever it is pertinent that the correct barcode is used, this function is most useful.
Voyager® 1200g Single-Line Laser Scanner
Honeywell's Voyager® 1200g laser barcode scanner, built on the platform of the world’s best-selling single-line laser scanner, delivers aggressive scan performance on virtually all linear barcodes, including poor quality and damaged codes. Updated object detection, automatic in-stand detection and configuration enable class-leading presentation scanning that maximizes throughput. The 1200g laser scanner provides superior scan performance matched with a reliable design for a versatile linear scanning solution.
Voyager 1200g Single-Line Laser Scanner
Built on the platform of the world’s best-selling single-line laser scanner,
Honeywell’s Voyager® 1200g delivers aggressive scan performance on virtually all linear bar codes, including poor quality and damaged codes. Updated object detection, and automatic in-stand detection and configuration enable class-leading presentation scanning that maximizes throughput. Superior scan performance matched with a reliable design combine to provide a versatile linear scanning solution suitable for a wide variety of applications.
The intuitive Voyager 1200g provides fast and reliable scanning of linear bar codes across its full working range, minimizing the need for user training. Whether poorly printed, smudged or faded, the Voyager 1200g decodes difficult-to-read bar codes with ease. The Voyager 1200g also excels at scanning high density bar codes with resolution down to 3.5 mil, eliminating the need to purchase specialty scanners.
Designed to decrease downtime and service costs, the Voyager 1200g includes a single shock-mounted PCB that delivers greater impact resistance. A recessed button protected by an integrated rubber comold minimizes the impact of accidental drops. Added durability is provided in the form of a protected, scratch-resistant glass window and an IP42-rating.
The Voyager 1200g, the next installment in the world-renowned Voyager series, provides outstanding scan performance and reliability for end users seeking an exceptional linear scanning solution.
Features
• Outstanding Scan Performance on Poor Quality and Damaged Bar Codes: Maintains productivity by providing a worry-free linear scanning solution that minimizes the need for manual data entry
• Class-Leading Presentation Scanning: Increases throughput by providing object detection and automatic in-stand detection and configuration
• Multi-Interface: Minimizes costs by delivering support for USB, keyboard wedge, and RS232 interfaces in a single scanner
• Superior Out-of-Box Experience: Simplifies set up with tool-free stand assembly; automatic in-stand detection and configuration; and automatic interface detection and configuration
• Contemporary, Ergonomic Design: Ensures operator comfort and productivity by incorporating an integrated finger groove in a sleek, lightweight industrial design that fits well in most hands
• CodeGate® Technology: Enables users to ensure that the desired bar code is scanned before transmitting data, making the scanner ideal for use in menu scanning applications
Voyager 1200g Technical Specifications
Mechanical
Dimensions (LxWxH) 66 mm (3.0˝) X 180 mm (7.1˝) X 97 mm (3.8˝)
Weight 125 g (4.4 oz)
Electrical
Input Voltage 5 V +/- 5%
Operating Power 700mW; 140 mA (typical) at 5V
Standby Power 350mw; 70 mA (typical) at 5V
Host System Interfaces:
Multi-Interface / Includes RS232 (TTL +5V, 4 Signals) / KBW / USB (HID Keyboard, Serial, IBM OEM); RS-232C (+/-12V) and IBM RS485 supported via adapter cable
Environmental
Operating Temperature 0°C to 50°C (32°F to 122°F)
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Humidity 0% to 95% non-condensing
Drop Designed to withstand 30 drops to concrete from 1.5 m
Environmental Sealing IP42
Light Levels 0 - 70,000 lux
Scan Performance
Scan Pattern Single scan line
Scan Speed 100 scan lines per second
Scan Angle Horizontal: 30°
Print Contrast 10% minimum reflectance difference
Pitch, Skew 60°, 60°
Decode Capabilities Reads standard 1D and GS1 DataBar symbologies
Warranty 5 year factory warranty
For a complete listing of all compliance approvals and certifications, please visit www.honeywellaidc.com/compliance
For a complete listing of all supported bar code technologies and certifications, please visit www.honeywellaidc.com/symbologies
Typical Performance*
Narrow Width Depth of Field
5 mil (Code 39) 27 mm - 151 mm (1.1˝ - 5.9˝)
7.5 mil (Code 39) 16 mm - 216 mm (0.6˝ - 8.5˝)
10.4 mil (Code 39) 0 mm - 277 mm (0˝ - 10.9˝)
13 mil (UPC-A) 0 mm - 311 mm (0˝ - 12.2˝)
20 mil (Code 39) 0 mm - 367 mm (0˝ - 14.4˝)
*Resolution: 3.5 mil
*Performance may be impacted by bar code quality and environmental conditions
For more information:
www.honeywellaidc.com
Honeywell Scanning & Mobility
9680 Old Bailes Road
Fort Mill, SC 29707
800.582.4263
www.honeywell.com
Alle modellen: / All models:
-Honeywell Voyager 1200g, 1D, multi-IF, licht grijs (hw1200 - 1200g-1)
handscanner, retail, 1D, laser, IR barcode sensor , CodeGate function, 0-28cm leesafstand, multi interface (RS232, KBW, USB), protection class: IP42, apart bestellen, interface kabel, kleur: licht grijs
-Honeywell Voyager 1200g, 1D, multi-IF, zwart (hw1200sw - 1200g-2)
handscanner, retail, 1D, laser, IR barcode sensor , CodeGate function, 0-28cm leesafstand, multi interface (RS232, KBW, USB), protection class: IP42, apart bestellen, interface kabel, kleur: zwart
-Honeywell Voyager 1200g, 1D, multi-IF, kabel (USB, spiraal), licht grijs (hw1200u - 1200g-1USB-1)
Voordelig geprijsde demo/gebruikt apparaat beschikbaar van dit artikel
handscanner, retail, 1D, laser, IR barcode sensor , CodeGate function, 0-28cm leesafstand, multi interface (RS232, KBW, USB), protection class: IP42, incl.: kabel (USB, spiraal), tafelmontage, kleur: licht grijs
-Honeywell Voyager 1200g, 1D, multi-IF, kabel (USB, spiraal), zwart (hw1200usw - 1200g-2USB-1)
Voordelig geprijsde demo/gebruikt apparaat beschikbaar van dit artikel
handscanner, retail, 1D, laser, IR barcode sensor , CodeGate function, 0-28cm leesafstand, multi interface (RS232, KBW, USB), protection class: IP42, incl.: kabel (USB, spiraal), tafelmontage, kleur: zwart
-Honeywell Voyager 1200g, 1D, multi-IF, kabel (KBW, spiraal), licht grijs (hw1200w - 1200g-1KBW-1)
handscanner, retail, 1D, laser, IR barcode sensor , CodeGate function, 0-28cm leesafstand, multi interface (RS232, KBW, USB), protection class: IP42, incl.: kabel (KBW, spiraal), tafelmontage, kleur: licht grijs
-Honeywell Voyager 1200g, 1D, multi-IF, kabel (KBW, spiraal), zwart (hw1200wsw - 1200g-2KBW-1)
Voordelig geprijsde demo/gebruikt apparaat beschikbaar van dit artikel
handscanner, retail, 1D, laser, IR barcode sensor , CodeGate function, 0-28cm leesafstand, multi interface (RS232, KBW, USB), protection class: IP42, incl.: kabel (KBW, spiraal), tafelmontage, kleur: zwart
Garantie: Warranty:
60 Maanden, 60 Months
Uitbreiding garantie met, Extended warranty with::
-PE Service +8%
Beschikbaar toebehoren: Available accessories:
-Honeywell power supply, EU (ms9520nt - 46-00526)
power supply, EU, 1.0A at 5.2VDC, 90-255VAC at 50-60Hz46
-Honeywell cable, KBW (hw1200cabkbw - CBL-720-300-C00)
cable, KBW, coiled, black, 3 m, 5V external power with option for host power
-Honeywell holder (hw1200hold - HOLDER-004-U)
desktop/wall mount holder for Honeywell 1200g/1400g
-Honeywell stand (hw1200stand - STND-19R02-002-4)
Stand, 19cm stand height, dark grey
-Honeywell USB-cable (hw1200ucab - CBL-500-300-C00)
USB-cable, coiled, black, 3m
-Honeywell cable, USB (hw1200ucab2 - CBL-500-300-S00)
cable, USB, straight, black, 3m
-Honeywell USB-cable (hw1200ucab3 - CBL-500-500-C00)
USB-cable, coiled, black, 16.4'
-Honeywell USB-cable, industrial (hw1200ucabi - CBL-500-300-S00-01)
USB-cable, industrial, 5V host power, straight, black, 3m
-Honeywell Kabel, RS232 (hwcab020 - CBL-020-300-C00)
RS232 Cable, 5V, DB9 Female, coiled, black, 3m
Naast ons uitgebreide aanbod, kunnen wij ook de volgende versies en accessoires van dit product leveren. Contacteer ons.
In addition to our extensive offer, we also provide the following versions and accessories of this product. Contact us.
Type Art.nr.fabr.
-Cable: RS232 (5V signals), Gilbarco terminal, black, 8 pin modular, 3m (9.8´), straight CBL-GIL-300-S00-01
-Cable: RS232 (5V signals), Gilbarco terminal, black, DB9 Female, 3m (9.8´), straight CBL-GIL-300-S00-02
-Cable: RS232 (5V signals), NCR 787x, black, 8 pin modular, 3m (9.8´), straight, external power with option for 5V host power on pin 1 CBL-NCR-300-S00
-Cable: RS232 (+/-12V signals), Radiant 1550 POS terminal, black, 6-pin modular, 3m (9.8´), straight, host power on pin 6 CBL-430-300-S00
-Cable: RS232 TTL (5V signals), 2.3m (7.5´), Straight, for connection to Fiscal Printer CBL-421-230-S00
-Cable: RS232 (+/-12V signals), Verifone Ruby, Sapphire and Topaz Terminals, black, 8 pin modular, straight, host power on pin 8 CBL-431-300-S00
Prijs op aanvraag! Price on request!
